Male To Female ZrO2 Voa Variable Fiber Optic Attenuator Single Mode XDK

XDK Communication Equipment Huizhou Co., Ltd

Male To Female ZrO2 Voa Variable Fiber Optic Attenuator Single Mode XDK

Model Number : ST

Certification : ROSH,REACH

Place of Origin : CHINA

MOQ : 50

Payment Terms : T/T

Supply Ability : 10000 per month

Delivery Time : 3-7 days

Packaging Details : bag pack

Brand Name : XDK

Connector Type : ST

Fiber Type : SM, MM

Housing Material : Plastic or metal

Alignment Sleeve : Ceramic (ZrO2) or customized

Contact Now

Fiber optic Male to Female Singlemode Fiber Attenuator, Fixed Type

Description
The male-female attenuator is connected to a fiber optic connector at one end and a fiber optic adapter at the other end. Its attenuation is fixed,unadjustable.this range of fixed attenuator is mainly used to reduce optical power to target value in optical links. the attenuation value is in range of 0 to 30dB, which are all applicable for optical signal with wavelength ranging from 1250nm to 1600nm.

Features
 Excellent Changeability and Directivity
 100% optic test(Insertion Loss)
 Accurate attenuation
 Max operation power (0.5W)
 Low polarization related loss
 Individual package available
 Standard sleeve,Various adaptor option: LC,SC,FC,ST,MU etc.

Specification

Item Parameter
Connector Type ST,SC,FC,LC,MU
Fiber Type SM MM
Color Blue, Green, Metallic Beige, Metallic, Aqua
Testing Wavelength 1310nm, 1550nm 850nm, 1300nm
Insertion Loss 0~30dB
Return Loss PC≥ 50dB, APC≥ 60dB PC≥ 25dB
Attenuation Tolerance

0~5dB(±0.5dB)

5~30dB(±10% )

Power Handling ≤200mW
Housing Material Plastic or metal
Alignment Sleeve Ceramic (ZrO2) or customized
Operating Temperature -20℃ to +70℃
Storage Temperature -40℃ to +85℃

Application
 Fiber optical distributing frame
 Fiber optical network system
 Hi-speed fiber optical transmission system
 CATV system
 Long distance DWDM system
 Optical add-drop multiplexers(OADM)


Product Tags:

ZrO2 Fiber Optic Attenuator



Voa Fiber Optic Attenuator



XDK variable optical attenuator


Wholesale Male To Female ZrO2 Voa Variable Fiber Optic Attenuator Single Mode XDK from china suppliers

Male To Female ZrO2 Voa Variable Fiber Optic Attenuator Single Mode XDK Images
